TWISTPORT 35dBm 16.2 dBi 40 Degree Horn Antenna

Symmetrical Horn TP Antenna Gen2

TWISTPORT ™ Connector Back Antenna

Symmetrical Horn Antennas feature a symmetrical beam pattern with no side lobes, offering superior noise rejection and outstanding scalability options. They are perfect for high-density AP clusters and dense radio common areas. The Symmetrical Horn TP Antenna Gen2 features the evolving TwistPort ™ connector, a patent-pending fast-locking waveguide port. TwistPort ™ is nearly lossless and revolutionary in its easy use. The Symmetrical Horn TP Antenna Gen2 offers multiple RF improvements including performance and industrial design, such as an optically lighter antenna body and significantly improved antenna bracket. Radomes are made of more durable materials and all Gen2 antennas use only two different sizes.

TECHNICAL DATA

Antenna Connector: TwistPort ™ - Fast Locking Connection Point

Antenna Type: Horn

Materials: UV Resistant ABS Plastic, Polycarbonate, Polypropylene, Aluminum, Stainless Steel

Environment: IP55

Direct Mount Diameter: 30-90 mm

Temperature: -30 °C to +55 °C (-22 °F to +131 °F)

Wind Load: 44 N at 160 km/hr

Mechanical Tilt: ±25 °

Weight: 1.8 Kg / 3.9 lbs - single unit

GAIN

Frequency Range: 5180-6400 MHz

Gain: 16.2 dBi

Azimuth Beam Width: -3 dB H 27 ° / V 27 °

Height Beam Width: -3 dB H 27 ° / V 27 °

Azimuth Beam Width: -6 dB H 40 ° / V 40 °

Height Beam Width: -6 dB Y 40 ° / V 40 °

Front to Back Ratio: 35 dB
